Equinox

Tile

Tile

This component allows users to quickly understand options and interact with them and can group related actions or information

Classic Tile

Usage

class TestScreen : EquinoxScreen<EquinoxViewModel>() {

    @Composable
    override fun ArrangeScreenContent() {
        Column(
            modifier = Modifier
                .fillMaxSize(),
            horizontalAlignment = Alignment.CenterHorizontally,
            verticalArrangement = Arrangement.Center
        ) {
            Tile(
                icon = Icons.Default.Settings, // representative icon
                text = "Settings", // representative text
                contentColor = Color.White, // customize the content color
                onClick = {
                    // your action
                }
            )
        }
    }

}

Customization

Check out the table below to apply your customizations to the component:

Parameter	Description
`modifier`	The modifier to apply to the container `Card`
`size`	The size of the tile
`shape`	The shape of the tile
`containerColor`	The color scheme to apply to the tile
`contentColor`	The color of the content, icon, and the text
`elevation`	The elevation of the tile
`iconSize`	The size of the `icon`
`fontWeight`	The weight to apply to the `text`
`textStyle`	The style to apply to the `text`

Appearance

Mobile

Desktop & Web

Dashed Tile

Usage

class TestScreen : EquinoxScreen<EquinoxViewModel>() {

    @Composable
    override fun ArrangeScreenContent() {
        Column(
            modifier = Modifier
                .fillMaxSize(),
            horizontalAlignment = Alignment.CenterHorizontally,
            verticalArrangement = Arrangement.Center
        ) {
            DashedTile(
                icon = Icons.Default.Settings, // representative icon
                text = "Settings", // representative text
                onClick = {
                    // your action
                }
            )
        }
    }

}

Customization

Check out the table below to apply your customizations to the component:

Parameter	Description
`modifier`	The modifier to apply to the container `Card`
`strokeWidth`	The stroke width to apply as dashed effect
`intervals`	The number of the interval from each part of the line
`phase`	The pixel offset for the intervals
`size`	The size of the tile
`cornerRadius`	The radius of the tile
`containerColor`	The color scheme to apply to the tile
`contentColor`	The color of the content, icon, and the text
`iconSize`	The size of the `icon`
`fontWeight`	The weight to apply to the `text`
`textStyle`	The style to apply to the `text`

Appearance

Mobile

Desktop & Web

Dynamic Tile

Useful to execute action when clicked and dynamically change its style to best represent the action or the subject that the tile represents

TileStyle

Style	Description
`DEFAULT`	The default style to draw a tile for general purposes
`DASHED`	The dashed style to draw a dashed-borders tile, for example to represent an unavailable action etc...

Usage

class TestScreen : EquinoxScreen<EquinoxViewModel>() {

    @Composable
    override fun ArrangeScreenContent() {
        Column(
            modifier = Modifier
                .fillMaxSize(),
            horizontalAlignment = Alignment.CenterHorizontally,
            verticalArrangement = Arrangement.Center
        ) {
            var settingsAvailable by remember { mutableStateOf(true) }
            DynamicTile(
                icon = Icons.Default.Settings, // representative icon
                text = "Settings", // representative text
                applyStyle = {
                    // logic to apply the style
                    if (settingsAvailable)
                        TileStyle.DEFAULT
                    else
                        TileStyle.DASHED
                },
                onClick = {
                    // your action
                    settingsAvailable = !settingsAvailable
                }
            )
        }
    }

}

Customization

Check out the table below to apply your customizations to the component:

Parameter	Description
`modifier`	The modifier to apply to the container `Card`
`strokeWidth`	The stroke width to apply as dashed effect
`intervals`	The number of the interval from each part of the line
`phase`	The pixel offset for the intervals
`size`	The size of the tile
`cornerRadius`	The radius of the tile
`containerColor`	The colors scheme to apply to the tile
`contentColor`	The color of the content, icon and the text
`elevation`	The elevation of the tile
`icon`	The representative icon
`iconSize`	The size of the `icon`
`text`	The representative text
`fontWeight`	The weight to apply to the `text`
`textStyle`	The style to apply to the `text`
`applyStyle`	The logic to apply the style to the tile
`onClick`	The action to execute when the tile has been clicked
`outerModifier`	The modifier to apply to the outer `Column` made-up this component
`innerModifier`	The modifier to apply to the inner `Column` made-up this component
`verticalArrangement`	The vertical arrangement of the `content`
`content`	The content to display inside the container

Appearance

Mobile

Desktop & Web
